Laser performance advantages

1. Korea import 7 joints arms
2. Imported Lambda Lens
3. 10mm adjustable spot size
4. High-power flat-top square wave power supply

5. Uniform spot energy distribution
6. Extremely high reliability and energy stability
7. Pulse width 350Ps
8. Water electricity separation

System's photoelectric performance parameters

Working laser wavelength: 1064nm/532nm, (Fractional handle)
Laser pulse width: 350Ps;
The maximum output single pulse energy at the end of the light guide arm is 500mJ@1064nm; 300mJ@532nm;
Display error between laser output energy and preset value: ≤±20%;
Spot size: 2-10mm continuously adjustable, the error is not more than ±20%
Aiming light wavelength 635nm
The distance between the center of the spot in the operation area and the center of the aiming spot is ≤0.5mm.
